| Working Length MM | Top Roll MM | Bottom Roll MM | Prebending Capacity MM | Motor HP |
| 1250 x 3 | 100 | 90 | 1 | 2 |
| 1250 x 6 | 125 | 105 | 3 | 3 |
| 1250 x 10 | 150 | 125 | 6 | 5 |
| 1250 x 12 | 175 | 140 | 8 | 7.5 |
| 1250 x 16 | 190 | 150 | 10 | 7.5 |
| 1250 x 20 | 200 | 160 | 12 | 10 |
| 1250 x 25 | 240 | 200 | 16 | 15 |
| 1500 x 3 | 115 | 100 | 1 | 3 |
| 1500 x 6 | 140 | 115 | 3 | 5 |
| 1500 x 10 | 160 | 135 | 6 | 7.5 |
| 1500 x 12 | 180 | 150 | 8 | 7.5 |
| 1500 x 16 | 200 | 160 | 10 | 10 |
| 1500 x 20 | 215 | 170 | 12 | 12.5 |
| 1500 x 25 | 250 | 215 | 16 | 20 |
| 2000 x 6 | 160 | 135 | 3 | 5 |
| 2000 x 10 | 185 | 150 | 6 | 7.5 |
| 2000 x 12 | 205 | 160 | 8 | 10 |
| 2000 x 16 | 215 | 175 | 10 | 12.5 |
| 2000 x 20 | 230 | 190 | 12 | 15 |
| 2000 x 25 | 275 | 230 | 16 | 20 |
| 2500 x 6 | 175 | 150 | 3 | 7.5 |
| 2500 x 10 | 200 | 170 | 6 | 10 |
| 2500 x 12 | 230 | 180 | 8 | 15 |
| 2500 x 16 | 240 | 200 | 10 | 20 |
| 2500 x 20 | 260 | 215 | 12 | 20 |
| 2500 x 25 | 300 | 260 | 16 | 30 |
| 3000 x 10 | 240 | 200 | 6 | 15 |
| 3000 x 12 | 260 | 220 | 8 | 20 |
| 3000 x 16 | 275 | 225 | 10 | 20 |
| 3000 x 20 | 290 | 250 | 12 | 25 |
| 3000 x 25 | 340 | 290 | 16 | 40 |
