| Model No. | Ros-1 | Ros-2 | Ros-3 | Ros-4 | Ros-5 | Ros-6 | Ros-7 | Ros-8 | Ros-9 | Ros-10 |
| Capacity in Tons | 20 | 25 | 65 | 80 | 100 | 100 | 120 | 140 | 160 | 200 |
| Bending Cap. (Length x Thick) | 1525 x 1.6 | 2030 x 1.6 | 2030 x 4 | 2540 x 3.25 | 2540 x 4.5 | 3125 x 3.25 | 2540 x 6 | 2030 x 8 | 3125 x 6 | 3125 x 8 |
| Dis. Between Housing | 1120 | 1220 | 1220 | 1700 | 1700 | 1700 | 1700 | 1420 | 1900 | 1900 |
| Stroke Length | 50 | 50 | 76 | 76 | 76 | 76 | 76 | 76 | 76 | 76 |
| Stoke Per Minute | 32 | 32 | 25 | 25 | 25 | 25 | 20 | 20 | 20 | 20 |
| RAM Adjustment | 25 | 25 | 25 | 25 | 25 | 22 | 22 | 22 | 22 | 20 |
| Shut Height Ram Stroke Down | 200 | 200 | 250 | 250 | 275 | 275 | 275 | 275 | 275 | 350 |
| Table Height | 760 | 760 | 800 | 800 | 800 | 800 | 900 | 900 | 900 | 900 |
| Main Motor HP | 3 | 5 | 7.5 | 10 | 15 | 15 | 20 | 25 | 25 | 30 |
| RAM Adjustment Motor HP | Manual | 1 | 1 | 1.5 | 2 | 2 | 2 | 2 | 2 | 2 |
| Die Space Length x Width | 1525 x 125 | 2030 x 125 | 2030 x 150 | 2540 x 150 | 2540 x 200 | 3125 x 200 | 2540 x 250 | 2030 x 250 | 3125 x 250 | 3125 x 250 |
| Machine Length (LxR) | 1800 | 2300 | 2300 | 3050 | 3050 | 3250 | 3150 | 2600 | 3300 | 3300 |
| Machine Width (FxB) | 1100 | 1100 | 1100 | 1600 | 1600 | 1750 | 1750 | 2160 | 1850 | 1850 |
| Machine Height | 2150 | 2300 | 2300 | 2600 | 2600 | 3000 | 3100 | 3200 | 3200 | 3200 |
| Weight Approx. | 2150 | 2450 | 3300 | 5500 | 6900 | 7800 | 8300 | 6500 | 9400 | 12500 |
