| Particulars | Ft. 6 |
Ft. 8 |
Ft. 10 |
Ft. 12 |
Ft. 14 |
Ft. 16 |
Ft. 20 |
| Length of bed | 10' | 13' | 16' | 19' | 22' | 25' | 31' |
| Length of Table | 6½' | 8½' | 10' - 9" | 12' - 9" | 14' - 9" | 16' - 9" | 21' |
| Stroke of Table | 6' | 8' | 10' | 12' | 14' | 16' | 20' |
| Width of bed | 21" | 25" | 25" | 35" | 35" | 35" | 35" |
| Width of Table | 26" | 32" | 32" | 42" | 42" | 42" | 42" |
| Maximumu width between uprights | 3' | 4' | 5' | 6' | 6' | 6' | 6' |
| Maximum height under cross rails | 2.3/4' | 4' | 4' | 6' | 6' | 6' | 6' |
| Method of Driving Planner | BELT DRIVEN | ||||||
| Method od Driving Table | RACK AND PINION | ||||||
| Motor required to drive | 3 H.P. | 5 H.P. | 7½ H.P. | 10 H.P. | 15 H.P. | 20 H.P. | 25 H.P. |
| Weight Approximate in Kgs. | 5000 | 7600 | 9000 | 16000 | 19000 | 22000 | 24000 |
