| Specifications | Unit | Standard Specifications |
| Table | ||
| Table Size | mm x mm | 400 x 700 |
| No./Width/CD of T-Slots | No./mm/mm | 3/14/125 |
| Max. Safe load on table | kg | 300 |
| Traverses | ||
| X-axis | mm | 510 |
| Y-axis | mm | 400 |
| Z-axis | mm | 400 |
| Distance from table to spindle face | mm | 150-550 |
| Feed Rates | ||
| Cutting feed rates | mm/min | 1-10000 |
| Rapid feed rates X/Y/Z axes | m/min | 36/36/36 |
| Spindle | ||
| Speed | rpm | 80-8000 |
| Max Power (cont/30 min) | KW | 5.5/7.5 |
| Taper | No. | BT40 |
| Auto Tool Changer | ||
| Number of tools | Nos | 20 |
| Max.tool diameter with adj | mm | 80 / 125 |
| Pocket full/empty | ||
| Max. tool length | mm | 200 |
| Max. tool weight | kg | 6 |
| Tool change time (tool to tool) | sec | 2.5 |
| Chip to Chip time | sec | 4.5 |
| Accuracy | ||
| Positioning | mm | +/-0.005 |
| Repeatability | mm | +/-0.003 |
| Installation Data | ||
| CNC System | Fanuc OiMD/ Siemens 828D Basic M | |
| Machine width x depth | mm x mm | 1800 x 2720 |
| Machine height | mm | 2660 |
| Machine weight | kg | 4500 |
| Pneumatic supply | bar | 6 |
| Total connected load | KVA | 15 |
| Power supply | 415V, 50Hz, 3 Phase |
